Features ...............................................................................................................................

  1. Excellent mechanical and environmental performance.
  2. Small cable diameter, light cable weight, self-supporting, easy to install.
  3. Low dispersion and attenuation.
  4. Medium Density Polyethylene Jacket: low friction installation, excellent protection from environmental hazards.
  5. Stainless steel or galvanized steel is self-supporting.
  6. Load-supporting element is made of zinc-coated wire that provides a high resistance grade to long tension.
  7. High-strength loose tube that is hydrolysis resistant.
  8. Light self-supporting cable with the figure 8 shape.

Applications .........................................................................................................................

  1. Suitable for aerial duct and buried method
  2. Long-distance and local area network communication
  3. CATV & computer network system
  4. Core Network, Metropolitan Area Network, and Access Network Outdoor Optical Cable
  5. Laying method: overhead, pipeline

Specifications .......................................................................................................................

Fiber
Count		 Nominal
Diameter(mm)		 Nominal
Weight(kg/km)		 Allowable
Tensile Load(N)		 Allowable Crush
Resistance(N/100mm)
Short Term Long Term Short Term Long Term
2~12 6.0x12.5 85 4000 2000 200 100
>12 Available upon customer's request!

Fiberroom Services ..........................................................................................................

  1. Any questions will be replied to within 24 hours.
  2. Professional manufacturer, Welcome to visit our company.
  3. 100% test before shipping.
  4. OEM/ODM is available (As required print logo and customized color).
