Features ...............................................................................................................................
- Apply to wall-mounted Hold-up installation.
- High-strength material with good weather adaptability and UV resistance.
- Port into the end and leakage design, easy construction, no need to open the box.
- Box can be installed wall-mounted or poled-mounted, and is suitable for both indoor and outdoor use.
- Different color adapters are supported to distinguish the box channels.
- Water-proof, dust-proof, anti-aging, protection level up to IP68.
Applications .........................................................................................................................
- Smart Broadband
- Fiber to the home
- Broadband cable TV
- Local area network
Specifications .......................................................................................................................
| ITEM | Parameters | Remarks |
| External dimension | 115*86*25mm | |
| Scope of application | 3.0*2.0mm 、φ3.0mmDrop cable | |
| Support adapter | SC-SX | or LC-DX adapter |
| Adapter Qty’(Max) | 1 pcs | |
| Capacity(Max) | 1 port | or LC 2ports |
| Disc fiber curvature radius | ≥20mm | |
| Additional loss of optical fiber disk | ≤0.01dB | |
| Material | PC+ABS | Customizable |
| Color | White | Customizable |
| Weight | 0.1KG | |
| Operating temperature | -40 ~ +65℃ |
Fiberroom Services ..........................................................................................................
- Any questions will be replied to within 24 hours.
- Professional manufacturer, Welcome to visit our company.
- 100% test before shipping.
- OEM/ODM is available (As required print logo and customized color).
