Features ...............................................................................................................................
- Small size, Low cost.
- Up to 24 fibers.
- Uni-tube gel-filled construction for superior fiber protection.
- Two parallel FRP wire and overall glass yarn to enhance tensile resistance.
- And protect the cable from mechanical damage.
- Designed for use with inexpensive attachment hardware.
- Self-supported no messenger needed.
Applications .........................................................................................................................
- Duct, Aerial
- FTTx, Access.
Specifications .......................................................................................................................
| Fiber Count | Nominal
Diameter (mm)
|
Nominal Weight
(kg/km)
|
Allowable Tensile Load (N) | Allowable Crush
Resistance (N/100mm)
|
Aerial Install span with 1% sag | ||||
| Short Term | Long Term | Short Term | Long Term | NESC Light | NESC Medium | NESC Heavy | |||
| 2~12 | 4.5 X 8.0 | 39 | 1800 | 750 | 2000 | 800 | 100meters | 80meters | 50meters |
| 14~24 | 4.9X8.4 | 45 | 1800 | 750 | 2000 | 800 | 80meters | 60meters | 40meters |
