Features ...............................................................................................................................

  1. Low insert loss
  2. Single Fusion design
  3. Uniform power splitting
  4. Compact size
  5. High stability and reliability
  6. Standard: Rohs complaints

Applications .........................................................................................................................

  1. CATV system
  2. Telecommunication systems
  3. Digital, Hybird, and AM-Video systems
  4. Fiber sensor
  5. Monitoring systems

Parameter .......................................................................................................................

Category Specification
Working Wavelength nm 1260～1650
Test Wavelength nm 1310&1490&1550
Insertion Loss exclude connector dB ≤10.5
With connector dB ≤11
Channel Uniformity dB ≤0.8
Polarization Dependent Loss-PDL dB ≤0.2
Directivity dB ≥55
Return Loss dB ≥55
Operating Temperature ℃ -40～+85

PLC Splitter Type .......................................................................................................................

Product Model 1X2、1x3、1X4、1X6

1X8、2x2、2X4、2X8

 1X10、1x12、1X16 2X16 1X32 2X32 1X16、2X64

Fiberroom Services ..........................................................................................................

  1. Any questions will be replied to within 24 hours.
  2. Professional manufacturer, Welcome to visit our company.
  3. 100% test before shipping.
  4. OEM/ODM is available (As required print logo and customized color).
